2026 T16-10 Tandem Axle Flatbed

GVWR: 14,340 lbs.
Capacity: 10,000 lbs.
Size: 16′

PRODUCT IMAGES

SPECIFICATIONS

The unique Air-tow flatbed uses a totally different concept to make loading easier and safer. The trailer deck remains completely level as it raises or lowers hydraulically in less than 30 seconds. At ground level, you simply drive your equipment onto the trailer. It is especially useful for equipment with poor traction or low ground clearance such as scissor lifts, sweepers, pavement rollers, etc. Air-tow eliminates the need for difficult tilt beds or dangerous loading ramps, making it a one-man job even in adverse weather conditions.

FEATURES

8 Heavy-Duty D-Rings
Adjustable Chain
Adjustable Coupler
Bright LED Lights
Durable Powder Coat Paint
Extra-Wide Deck
Fenderless
Ground-Level Loading
Non-Tilting Deck
Remote Control
Rubber or Air Suspension
Swing-Arm Axles
GVWR 14,340 lbs.(9,995 lbs. also available)
Capacity 10,000 lbs.
Weight (varies w/ opt.) 4,340 lbs.
Deck Width 6’3″ (75″)
Deck Length (inc. 18″ dovetail) 16′
Deck Material Diamond Steel Plate
Dovetail Size 18″
Overall Width 102″
Axles Tandem
Wheels/Tires 16″ – 12 Ply
Brakes (electric-std.) Electric
Suspension (rubber/air) Rubber
Lift Mechanism Hydraulic
Coupler 2 5/16″ Ball
Color Royal Blue
